Temperature Rise: 70℃ Max (Rated current)
Step Angle Accuracy: 5%
Ambient temperature: -20℃~+50℃
Insulation Resistance: 100MΩ 500V DC
Dielectric Strength: 1500V AC 1min
Insulation class: B
Technical parameters
| Motor Model | StepAngle(°) | HoldingTorque(N.m) | (Drive)OperatingVoltage(V) | RatedCurrent(A) | Phase Inductance (mH) | Phase Resistance(Ω) | RotorInertia(kg.m²) | Weight(kg) | MotorLength(mm) |
| 110BYG350A | 1.2 | 8 | 220 | 3.7 | 11.9 | 1.00 | 8.6 | 5.5 | 139 |
| 110BYG350B | 1.2 | 12 | 220 | 4.5 | 11.5 | 0.76 | 11.9 | 7.1 | 162 |
| 110BYG350C | 1.2 | 16 | 220 | 6.0 | 19 | 1.28 | 14.8 | 8.8 | 187 |
| 110BYG350D | 1.2 | 20 | 220 | 6.8 | 22 | 1.24 | 19.8 | 11 | 221 |
